Cub Cadet Pro Z 972 SD

The Cub Cadet Pro Z 972 SD boasts a 999 cc Kawasaki FX1000v engine,
16 cc Parker HTG transmission, and a 72″, triple-7-gauge, fabricated steel cutting deck with top, bottom, and side reinforcements.

With dual rear wheels and weighted front rims, this mower provides excellent traction on slopes up to 25-degrees.

This zero turn is designed with a high-back Air-Ride suspension seat with EVC cushion and padded armrests, ground speeds up to 12 mph, a high-density & impact-resistant rubber discharge chute, and a high performance steering wheel with electronic power steering and foot-pedal control.

SEE IT IN ACTION

FEATURES:

• 999 cc Kawasaki FX1000v engine
• 72 inch triple-7-gauge fabricated steel cutting deck with top, bottom and side reinforcements
• 16 cc Parker HTG transmission
• Dual rear wheels and weighted front rims for excellent traction on slopes up to 25-degrees
• Fully welded frame
• Steering wheel with electronic power steering and foot-pedal control
• High-back Air-Ride suspension seat with EVC cushion and padded armrests
• High-density & impact-resistant rubber discharge chute

SPECIFICATIONS

Engine

• Engine Brand Kawasaki
• Engine Model FX1000v
• Engine Displacement 999cc
• Engine Output 35 HP
• Fuel Tank Capacity Twin 7.45 gal. tanks (14.9 gal. total) with electronic fuel gauge

Drive System

• Transmission Parker HTG 16cc pump / 310cc wheel motor
• Forward Speed 12 mph
• Reverse Speed 6 mph

Cutting Deck

• Deck Cutting Width 72″
• Deck Material Fabricated 7ga. (.187”) steel shell
• Deck Engagement (PTO) Electronic fingertip engagement pto
• Deck Construction top plate 7ga. bottom reinforcement ¼” rolled leading edge
• Spindle Construction 8″ sealed cast aluminum housing (maintenance-free)
• Blade(s) Triple-blade / High-lift blade (standard) Marbain Blade
• Cutting Height Range 1″ – 5″
• Anti-Scalping 4 Front HD w/ Bushings & Grease Zerk
• Deck Positions Foot pedal with spring assist 16 Positions

Chassis

• Frame Fully welded, full-length 3/8 x 5″ laser cut steel / integrated tie-down slots
• Front Axle(s) Front Axle / Yokes 2″ x 3″ solid axle tube with ISO dampening suspension
• Front Tires 16″ x 6.5″ – 8″ (turf) with weighted rim
• Rear Tires Dual TERRA TRAC Tread 25″ x 9″ – 12″ (18″ trac width)
• ROPS 2″ x 2″ spring-latch tool-less foldable 3 position
• Bumper 5/16″ Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch
• Yokes 1/2″ thick steel front yokes

Controls

• Brakes Hand-operated lever with integrated hydro pump release lever
• Steering Wheel Control High Performance Steering Wheel with electronic power steering & foot-pedal control

Dimensions

• Dimensions L/W/H 88″ L x 85″ W x 49″ H
• Weight (approx.) 1850 lbs.

Additional Specifications

• Hour Meter Standard electronic
• Discharge Chute High-density, impact-resistant rubber
• Cup Holder Integrated into Side Pod

Warranty

• Deck Shell Warranty 5 year / 1,750 hour limited deck construction warranty
• Commercial Warranty 3 year / no hour limit commercial warranty
